6 ft 11 in

20 ft

2550 libras

10,400lb

6 in X 8.2# Channel Iron W/ Front Corners 45ed

9 in x 72 in Tear Drop Smooth W/ Smooth Backing Plates

Equalizer W/ 5-Leave Eye-to-Eye Springs System

New ST225/75/R/15 in Radial Load Range "D" 8-Ply

20 ft & Smaller 5 in X 3 in X 1/4 in Angle Iron Wrap Around * 22 ft & Larger 5 in X 3 in X 5/16 in Angle Iron Wrap Around

Undercoating: Completely Coated W/ A Durable Protective Finish | Exterior Finish: Painted With A Newly Inovated, Durable High Gloss * Acrylic Polyurethane Full Polyurethane Full Two-Component Finish | Est Prepping: 2 Stage Degreasing And Acid Phosphate Wash W/ Rust- * Inhibitor To Ensure Maximum Paint Adhesion | Dove Tail: 4 ft - For Easy Low To The Ground Loading | Tie Downs: 3 in Stake Pockets(16' & Smaller-10)(18'12)(20'-14) * Four- Weld On Top Of The Floor D-Rings | Bump Rails: 2-3/8 in Pipe Bump Rail / 8 in Tall | Plug: 7 - Way Molded Plug Harness /Grounded To Frame | Jack: 7K Sidewind Drop Leg W/ Sand Foot, Set In Center

5 ft Slide In Rolled Channel Iron W/ Holders

2-5/16 in - 12.5K Ram w/ Hole Cover Plate

One rear -Electric Brake w/ Break Away & Charger

3 in x 2 in x 3/16 in Angle Iron On 24" Centers

Two - 5.2K Axles Cambered & Accu-Lube Hubs

6- Hole Powder Coated Silver Mods

1/4 in Chain w/ Safety Latching Hooks

1/8 in Steel Diamond Tread Plate Sheet Metal

"LED" Running, Stop, Turn, and Clearance

A Limited Two Year Kearney Guarantee
