2,990 Lbs. | GAWR: 3,500 Lbs.

One 3,500 Lbs.

Multi-Leaf Spring

15 in

15 in White Spoke 5 Bolt

2 in Bulldog (7,000 Lbs.)

Two 5/16 in Grd. 70 with Safety Latch Hook

Capacity: 3,500 Lbs.| Jack: 4,000 Lbs. Top Wind (Swing-up) | Hooks: 1/2 in Rod

3 in Channel Fold Back Tongue

Schedule-30, 1-1/2″ Pipe

2-1/2 in x 2-1/2 in x 3/16 in Angle

2-1/2 in x 2-1/2 in x 3/16 in Angle

15 in Tail 2 in x 2 in x 3/16 in Angle

2 in Treated Pine Lumber Deck

D.O.T. Stop, Tail, Turn and Clearance (all LED)

7-Way RV

Painted with 2 Coats Automotive Quality Acrylic Enamel | Mechanical and/or Chemical Pretreatment for Maximum Paint Adhesion

5 ft

8 ft
