2027 Homesteader Trailers Champion 816AB

Champion Enclosed Cargo Trailers

The Champion series features include: 102″ wide body, .080 PolyCor Exterior Siding, 3/4″ exterior grade plywood flooring, 3/8″ plywood wall liner, floor cross members and wall posts at 16″ O.C., and 2×6 tube steel main rail construction. The exterior includes aluminum tread plate front corners and stone guard. Inside, the Champion series is appointed with all-aluminum trim along the floor and ceiling. The Champion is equipped with a PolyCor ceiling liner, 2 interior lights, and four 5k rated D-rings as standard features. Standard door configuration includes a 32” side door with step well and a rear ramp door with a 4’ beaver tail for smooth loading. The Champion rides on Dexter Rubber TorFlex axles and trailer rated radial tires. For elite auto transport, the Champion series is a true winner!

Features may include:

• .080 ACP (Aluminum Composite Panel) Siding
• 102" Wide Body
• 11 Year Manufactured Limited Warranty on Torsion Axles
• 16" O.C. Full Height Crossmembers
• 2 Interior Lights with Switch
• 24" Aluminum Treadplate Stoneguard
• 2x6 Tube Steel Frame
• 3 Year Limited Structural Warranty
• 3/4" Exterior Grade Plywood Flooring
• 3/8" Plywood Interior Wall Liner
• 32" Side Entry Door with Steel Stepwell
• 4 Wheel Brakes
• 4' Beavertail at ramp door
• 4-5000# D-Ring Tie Downs
• 5000 lb Tongue Jack-Tandem Models
• 5200 lb EZ Lube Torsion Axles
• 60" Tongue w/ADJ 2 5/16" Coupler
• 7' Interior Height
• 7-way Molded Light Plug
• 82" Between Wheel Wells (8.5' wide models)
• 94" Opening (8.5' Wide Models)
• Aerodynamic Styling
• Aerodynamic TPO (Thermo-Plastic Poly-Olefin) Nosecap
• Aluminum Door Holdbacks
• Aluminum Fenders
• Automotive Quality Gaskets & Seals
• Breakaway Kit with Battery and Charger
• Chrome Hub Covers
• D.O.T. Compliant Conspicuity Tape
• Door Grab Handles
• Door Hold Back Chains
• Enclosed Front Header and Rear Spring Cover
• Finished & Trimmed White Polycor Ceiling
• Floor Crossmembers 16" O.C.
• Flow thru Vent System
• Independent Torsion Suspension Axles
• Keyed Lockable Door Hasp
• LED Compliant Lighting
• Modular Style Steel Wheels
• NATM Certified
• One Piece Aluminum Roof
• Radius Front Aluminum Treadplate Corners
• Ramp Door Extension Flap
• Rear Ramp Door w/ Spring Cable Assist
• Rear Spoiler w/ Loading Light
• Semi-Trailer Style Door Fastener Bars with Zinc-Coated Finish
• Trailer Rated Radial Tires
• Tubular Steel Roof Supports 16" O.C.
• Tubular Steel Wall Studs 16" O.C.
• Under Coated Frame

Options:

• 110V Electrical Options
• 48" Escape Door
• Air Conditioner
• Available in Five Colors
• Axle Upgrades
• Blacked Out Exterior
• Bonded Side Door
• Concession Doors
• E-Track
• Extra Sidewall Height
• Flushlock - Side Door
• Hydraulic Landing Gear (Gooseneck Only)
• Insulated Ceiling (Liner Required)
• Insulated Walls
• LED Ceiling Light
• PolyCor Wall Liner
• Rear Loading Lights
• Roof Access Ladder
• Side Ramp Door
• Spare Tire and Wheel
• Spare Tire Compartment
• Spread Axle (8.5' Wide Models)
• V-nose with ATP Point
• Walk on Roof
